| LED Driver IC | ||||||
| Device | Topology | VIN | Output Current | Dimming | Package Option | |
| min(V) | max(V) | (mA) | ||||
| HY3010 | PFM | 3 | 40 | 1000 | PWM | SOT-23-6L |
| BUCK | ||||||
| HY3110 | PFM | 7 | 36 | 1000 | PWM | SOIC-8L |
| BUCK | SOT-89 | |||||
| HY3015 | PWM | 3 | 40 | 1500 | External Circuit | TO252-5L |
| BUCK | ||||||
| HY7700 | PFM、PWM | 9 | 450 | External MOS | PWM、Linear | SOIC-8L |
| BUCK、BUCK-BOOST | ||||||
| HY3110 | PFM | 7 | 36 | 1000 | PWM | SOIC-8L |
| BUCK | ||||||
| HY7731 | Single-Switch PFC | 8 | 450 | External MOS | PWM | SOIC-8L |
| Voltage Regulator IC | ||||||
| Device | Topology | VIN | Current Ability | ENABLE | Package Option | |
| min(V) | max(V) | (mA) | ||||
| HY2596 | PWM | 5 | 40 | 3000 | PWM | SOT-23-6L |
| BUCK | TO263-5L | |||||
| HY5171 | PWM | 2.7 | 30 | 1500 | External Synchronization | SOIC-8L |
| BOOST、SEPIC | ||||||
| Other IC | ||||||
| Device | FUNCTION | VIN | Current Ability | ENABLE | Package Option | |
| min(V) | max(V) | (mA) | ||||
| HY2821 | Power LED Driver tool. | 5 | 40 | External Regulator | N/A | SOT-23-5L |
